ماژول رگولاتور DC به DC کاهنده 2 آمپر MINI-360

StepUp StepDown Buck Converter

Type: Mini-360

Non-isolated Step-Down

Synchronous Rectification

Size: approx. 17 x 11 x 3.8 mm

Input voltage: 4.75V - 23V

Output voltage: 1.0V - 17V

Current output: peak 2A , 1.8A long time

transfer efficiency : 96% (highest) Switching

frequency: 340 KHz

Output ripple: 30mV (no load) Load

regulation: ± 0.5%

Voltage regulation: ± 2.5%

Operating temperature: -40 ~ +85
